TEC Stocks IECC 2015 Energy Code Compliant Equipment

TEC stocks the largest array of commercial IECC 2015 energy code compliant equipment in the Chicagoland area.  Along with this we have the expertise to make sure the equipment we sell you meets the IECC 2015 energy code.

Stock in TEC’s Chicagoland Warehouses:

  • IECC 2015 Compliant Carrier and Bryant RTU’s up to 25 tons
  • IECC 2015 Compliant Carrier RTU’s with Staged Air Volume (SAV) for energy savings
  • Curb adapters matching Carrier and other competitors equipment
  • IECC 2015 Compliant Carrier and Bryant Split Systems up to 25 tons
  • IECC 2015 Compliant Code Compliant Economizers with Ultra Low Leak Dampers and Fault Detection
  • IECC 2015 Compliant Code Complaint Programmable Thermostats





Tower Tech Reaching New Heights in Chicago

340 On The Park was looking to reduce their rising costs of chilled water from the local utility by installing and operating their own chiller plant on the top floor of the building. They hired consultant Cyclone Energy Group to provide design, cost analysis, feasibility, and energy modeling services. TEC worked closely with Cyclone Energy to provide the owner with several options:

  • Option #1: Carrier Air Cooled Scroll Chillers
  • Option #2: Carrier 19XRV Centrifugal Water Cooled Chillers And Tower Tech Cooling Towers
  • Option #3: Carrier 23XRV Ultra High Efficient Water Cooled Screw Chillers in Series – Counter flow Arrangement and Tower Tech Cooling Towers

The Condo Board selected Option #3 which provides the most efficient design, largest utility rebate, and quickest return on investment. Click here and watch a video of the unique lifting operation.

The unique equipment selected offers unparalleled benefits not found in other conventional chillers and cooling towers.  Here are just some of the unique benefits:

Tower Tech Cooling Towers

  1. Multiple direct drive fan design provides inherent redundancy in the event of a fan failure
  2. 80% less drift heavily reduces water and chemical usage
  3. Pultruded FRP construction of the cooling tower eliminates corrosion and extends tower life
  4. Variable flow nozzles utilize the entire surface area of the media and increase energy efficiency at part load conditions
  5. Unique basin design keeps the water dark and at a high velocity virtually eliminating  the risk of algae and legionella growth
  6. Simple maintenance done from the ground level.  No more ladders and harnesses.

Carrier 23XRV Screw Chillers

  1. Simple design with only 3 moving parts (screws).  No inlet vanes or actuators to fail.
  2. Positive displacement design means no compressor surges.
  3. Rapid adjustment to load changes ensures maximum comfort for the tenants
  4. Series Counter Flow design enhances the efficiency an additional 5-10% over the competition
  5. No compressor teardowns required
  6. 50 year bearing life

For more information on this job or the equipment used, please contact Mark Simbrowky at mark.simbrowsky@tecmungo.com

Aeroseal Duct Sealing at Loyola Cudahy Library

Loyola Cudahy Library, Chicago, IL – Completed 2/2/16

After a remodel of the Loyola Cudahy Library, the ductwork needed to be sealed in order to comply with code. To accomplish this, Aeroseal Solutions, Inc of McHenry, IL performed the Aeroseal duct sealing method in order to reduce the leakage.

Initial Leakage: 656 cfm

Final Leakage: 16.8 cfm

RESULT: 97.4% Reduction in Leakage

















 97.6% reduction in duct leakage                                        97.1% reduction in duct leakage













  96.9% reduction in duct leakage                                        98.4% reduction in duct leakage



Applications, Advantages & Highlights of KN Boilers

Modern boiler applications call for technology that is innovative, flexible and adaptable. KN Series cast iron boilers were purposefully engineered to live up to today’s toughest applications and challenges, providing versatility in boiler system configuration and installation without sacrificing the bottom line.

In this day and age, the word ‘hybrid’ gets thrown around often. But what about the terms ‘base load’ or ‘mixed-boiler? Within the commercial boiler market, the concept behind these configurations is simple, lower the upfront equipment cost of a complete condensing boiler plant by incorporating new units into an existing and less expensive non-condensing boiler plant.

With a hybrid boiler system that combines KN Series condensing boilers within an existing, non-condensing boiler plant, operators are able to meet total BTU requirements while optimizing overall system performance, increasing boiler efficiency under various climate, seasonal and load conditions. By operating during most of the heating season, the condensing KN Series units provide the bulk of the high-efficiency BTU output when loop temperatures are low, while the existing and less-efficient non-condensing units act as supplemental boilers when outdoor temperatures fall and boiler loop temperatures increase. Continue reading

Aeroseal Duct Sealing at Iconic Wrigley Building

Wrigley Building, Chicago, IL – Completed 11/28/15

During a remodel of the 9th Floor of the Wrigley Building, when walls                             were torn down and the duct was exposed, the General Contractor was made aware of air pouring out of the duct work as a result of gaps causing leakage. The Aeroseal duct sealing method was used to reduce that leakage.

Initial Leakage: 430.2 CFM

Final Leakage: 31.4 CFM

RESULT: 92.7% Reduction in Leakage

TEC is in the Large Boiler Business!

TEC introduces a new commercial boiler line to our offering – KN from Advanced Thermal Hydronics (ATH).

Engineered to meet the demands of today’s commercial condensing boiler market, KN Series by Advanced Thermal Hydronics (ATH) are high efficiency condensing gas boilers built with the historically recognized reliability and strength of cast iron. As the first line of commercial boilers capable of realizing the full potential of cast iron, KN Series boilers take the heat-retention and durability of cast iron and couple it with the energy savings of fully modulating, highly efficient condensing boiler performance.

Capable of adapting to changing operating environments while generating 200,000 – 3,000,000 BTUs, KN Series boilers deliver environmentally friendly solutions for a wide range of boiler applications, all the while maintaining low fuel utilization and a small footprint. All KN Series models come equipped with HeatNet 3.0 boiler control software for precise system control through digital communication, and even have the option of remote monitoring through HeatNet Online.

Significant reductions in energy consumption, when coupled with low NOx and CO2 emissions, make KN Series’ complete line of cast iron, condensing gas boilers an environmentally friendly, cost-effective option that will last for years to come.

Go behind the scenes to see how KN Series boilers are made!

For more information contact your TEC representative.

Lake Geneva Geothermal Project

TEC partnered with a local engineering firm and contractor to design the best in comfort and energy efficiency for a residential project located in Fontana, WI.

TEC Territory Manager, Jose Ronchetta, worked extensively with a highly professional consulting engineering firm. The firm specializes in mechanical and electrical engineering for buildings, focusing on green and energy conservative designs. After many hours of consulting and engineering work, the job was ready for installation.

The impressive installation was completed by Ridgeway Home Services, a heating company that services the greater Chicagoland area. Ridgeway is considered a hydronics heating expert but also services and installs many other types of equipment, making it right for this project.

Project Quick Facts

  • Location: Fontana (Lake Geneva) WI
  • Size: 24,000 Sq Ft
  • Tons: 55
  • Solder Joints: Over 200
  • Bore Holes: 22
  • RAUGEO Pipe Used: Over 8,000 Ft

Equipment Highlights

  • Carrier Geothermal Splits
  • Carrier Fan Coils
  • RAUGEO Geothermal Pipe
  • Carrier Flow Centers
  • Grundfos Magna 3 Pumps

For more information about this project, contact Greg Joutras at 815-531-7414 or greg.joutras@tecmungo.com.

What the Mechanical Hub video series on the Fontana, WI project:

Oct. 29, 2015 – Fontana, WI Geothermal Project

Nov.4, 2015 – Video Teaser

Nov.11, 2015 – Carrier Geothermal Project

Nov.18, 2015 – Grundfos Magna Circulators

Nov.23, 2015 – REHAU PEXa Tubing



Aeroseal and its unique benefits

Aeroseal is a proven, patented technology that seals the duct from the inside out.Virtually every duct system has a substantial amount of duct leakage which has been accepted as a necessary evil in our industry. On average, commercial duct systems lose between 25-40% of heating & cooling energy through the duct work.

Features & Benefits of Aeroseal:

  • Reduces duct leakage by 90-95% – typical duct leakage rates are redces from 20-30%, down to 2-3%
  • Seals up to a 5/8” hole – seeks out and finds virtually every existing crack, hole or seam without removing existing duct wrap
  • Seals up to 10” of duct static
  • Saves Fan HP - A 15% leakage rate equates to a 40% increase is system fan HP
  • VERIFIABLE – as the duct is sealed, the system documents the initial leakage rate, the reduction in leakage and the final system leakage rate and graphs the sealing process in the final report
  • SYSTEM BALANCE – Supply, return and/or exhaust air is delivered to the spaces it was designed for. Reduces the practice of increasing sheaves and fan BHP to overcome system shortcomings
  • Durable – Aeroseal is warranted on commercial jobs for 3 years and has a life expectancy of 40+ years
  • Safe – Aeroseal emits no known carcinogens or toxic substances (MSDS attached)
  • Payback – Typical paybacks are between 2-7 years

Fore more information of Aeroseal, contact your TEC representative.

TEC now offers RAUGEO Geothermal Pipe

TEC has partnered with REHAU to offer RAUGEO Ground Loop Heat Exchange System.

This new offering allows contractors to take advantage of the unique properties and capabilities of a PEXa system.

The RAUGEO ground loop heat exchange system is a high efficiency energy source for both heating and cooling, offering numerous advantages in both installation and long term performance over traditional geothermal systems. The unique design and innovative materials allow the system to capitalize on the earth’s ability to provide and store heat energy. As part of a geothermal heat pump system, RAUGEO offers superior energy savings of up to 70% compared to traditional heating methods.

 RAUGEO System Features:

  • Pre-fabricated for single or double U-Bend design
  • Continuous coils up to 520 ft
  • Double U-Bends can increase borehole thermal conductivity
  • PEXa Double U-Bends require 10 – 30% less
  • borehole footage
  • Recognized by IGSHPA as an acceptable piping system



TEC offers extensive outdoor ground loop design work on all Geothermal and WHSP jobs. For more information contact your TM or local branch.

TEC & NEC Residential Territory Managers Receive BPI Certificate of Knowledge of Building Science Principles

All Residential Territory Managers at Temperature Equipment Corporation and National Excelsior Company, in all states, now hold the BPI Certificate of Knowledge of Building Science Principles. This means that our staff now has the expert knowledge of how building science interacts with the overall performance of a customer’s home. This program has provided Territory Managers with expertise on understanding the relationships between the following key systems within a home:

  • Building envelope
  • Heating
  • Air Conditioning
  • Insulation
  • Mechanical Ventilation
  • Lighting
  • Appliances
  • Other systems

Territory Managers at both TEC and NEC possess the fundamental knowledge and understanding of how these systems affect the comfort, health, and safety of your customers, as well as the durability and energy efficiency of the home itself.

Geothermal HVAC Systems & their Benefits

Carrier and Bryant recently launched new geothermal product lines. Geothermal HVAC systems have been used for over 60 years in the US and other Western countries, and their use is growing exponentially. While geothermal systems are more expensive to install than ordinary systems, they offer two key advantages. First, they offer significant long-term cost savings. The US Department of Energy has found that they can save the average home hundreds of dollars in utility costs while the system pays for itself in 8 to 12 years. Second, a geothermal HVAC system can be designed to handle multiple needs simultaneously. For example, this kind of system can work to heat water, a pool, and a house all at the same time.   Continue reading

New A/C Rebates for Municipal Electric in Naperville, St. Charles, Winnetka, and others

The State of Illinois Dept. of Commerce and Economic Opportunity (DCEO) has given Nicor Gas a grant to mimic their ComEd combo rebate program with municipal electric utilities.  Only certain muni’s are being included in this test program including three in Chicagoland.  The rules, dollar amounts ($720 to 1,020), and tiers (14.5 and 16 SEER) are basically the same as the ComEd program, but Continue reading

Energy Benchmarking Ordinance Approved by Chicago’s City Council

Chicago’s City Council passed the energy benchmarking and disclosure ordinance on Sept.11.  In adopting a new chapter of the Municipal Code we are launching a new chapter in Chicago’s path to being the most livable, competitive and sustainable city.  Information unlocks markets and this new legislation will bring cost savings, reduced environmental impact and new economic opportunity.  In the near term the City will Continue reading

How Efficient is the New Carrier 48LC WeatherExpert RTU?

Carrier accepted the DOE RTU challenge to meet the Integrated Energy Efficiency Ratio (IEER) of 18 or above for a 10 ton packaged RTU.  Carrier not only beat the 18 IEER requirement, they exceeded it by 15%.  The new WeatherExpert 48LC 10 ton RTU has IEER’s up to 21.0.  So, what does that actually mean to a building owner?  We decided to calculate two comparisons. Continue reading

TEC Now Stocks GE Hybrid Heat Pump Water Heaters to Meet DOE Rules

TEC is proud to now stock General Electric’s GeoSpring Hybrid Heat Pump Water Heaters.  The new 2015 DOE rules require all 55+ gallon electric water heaters to be rated with an energy factor (EF) of nearly 2.0 (depending on tank volume).  Electric resistance water heaters are generally less than 0.95 with a technology maximum of EF 1.0 and hence will be prohibited by law.  In a year and a half, heat pumps will be the only viable Continue reading

TEC, Carrier, ASHRAE, and Others Join the Advanced RTU Campaign

Older, inefficient commercial rooftop unit (RTU) air conditioning systems are common and can waste from $1,000 to $3,700 per unit annually, depending on the building size and type.  By replacing or retrofitting them, you can save money, improve your energy efficiency, make your building more comfortable, and help the environment.  The Advanced RTU Campaign (ARC) encourages commercial building owners and operators to replace their old RTUs with more efficient units or to retrofit their RTUs with advanced controls in order to take advantage of these benefits.

You can learn more at www.advancedrtu.org, including case studies, energy savings calculator, utility rebates, building awards, and more.

Chicago Introduces Ordinance to Make Energy Use Benchmarking Mandatory

To further cement Chicago’s status as a center for sustainability and green jobs, Mayor Rahm Emanuel today introduced an ordinance that would require the city’s largest buildings to benchmark their energy use and authorize the City to disclose the energy efficiency for these buildings publicly.  Below are the highlights as described by Benny Skelton of ASHRAE.  The Mayor’s press release can read at the link below. Continue reading

The Future of Commercial Building Efficiency

Check out this article in the ACHR News if you want a glimpse of the future of energy efficiency (see link below).  I will warn you that it is not sexy new HVAC products for you to sell.  It is all about the building functioning as a complete system.  It is written jointly by Dick Lord of Carrier (he is a Carrier Fellow with 40 years at Carrier engineering), Drake Erbe of Airxhange (he is the alpha dog there) and Robert Wilkins of Danfoss (former president of the company).  They are part of a new AHRI committee setup to focus on the energy efficiency of systems as a whole, not specific products. Continue reading
